The TRIUMPH RGB IP65 rated family !

To further facilitate outdoor event applications, the new TRIUMPH RGB 120000 laser projector has a better

sealing design. It has a sturdy waterproof shell that meets the IP65 standard, is 100% waterproof, and

allows people to use it in rainy days without weather restrictions.

Seeking for immense power, go with it!

Spec Power @ Light Source

Total Output @ Projector Window

Beam Profile

Modulation : Analog 50KHZ

Laser Class :  Class IV

Scanner

Galvo : EMS 9000 digital scanner 30Kpps
Scan Angle : 48° Max Optical

Interfaces & Controls

Control :  ILDA in (Differential)
Safety :  Key Switch
Remote Interlock :  5/8 pins from RJ45
Mains : Neutrik PowerCon® TRUE1 TOP

Optional Components

Embedded Controller :  Pangolin FB4 (upon request)
Electric motorized dichroic adjuster

Thermal Control

Cooling :  Active Cooling / Heating by TEC Peltier Elements

Heating : Heating rod
Ventilation : 60mm IP68 fan * 4, 80mm IP68 fan * 5

Electric

Operating Voltage :  AC 110V-240V
Power Consumption: 2700W Max

Physical

L * W * H :  510mm * 500mm * 359mm (Without Yoke & feet)
Weight : 77kg (With Yoke)
Housing Materials :  Black Anodized Aluminum
IP grade :  IP65
Packaging :  Flight case

Compliance

Compliance:  FDA/CDRH, CE

Warranty

Warranty: 24 months parts and labor
